Epson CO-FH01 Full HD 3LCD Projector

The Versatile Home Entertainment Projector.

The CO-FH01 is Epson's versatile lifestyle projector for both work and play. Featuring a Full HD resolution and 3,000 lumens1 of brightness, this all-in-one projector allows you to project a big screen experience in the home and office, at an affordable price. Even in bright rooms, this powerful yet affordable Full HD projector delivers high quality images anywhere, anytime. This is all thanks to Epson's 3LCD technology, which produces an equally high white and colour light output of 3,000 lumens1. Supersize and immerse yourself in your favourite movies and games with this Full HD projector, that's capable of creating an impressive 391-inch display.

      • Full HD resolution
      • Stunning Picture Quality up to 391"
      • 3000 lumens of Colour and White brightness1
      • 5W Speaker



Where to Buy

High Clarity
With 3,000 lumens1 of brightness and full HD resolution, you no longer need to worry about image clarity, even in bright daylight settings.

Bigger Is Better
Supersize and immerse yourself in your favourite movies and games with this Full HD projector, that's capable of creating an impressive 391-inch display, almost 5 times of a 80-inch TV.

Hassle-free Portability
Lightweight and compact design enables users to conveniently carry and install the projector in different environments3.

Projection Technology:


Projection Technology: RGB liquid crystal shutter projection system

Specifications of Main Parts:


LCD: Size: 0.62-inch (C2 Fine)
Native Resolution: Full HD (1080p)Light Source: Type: Lamp: 188W UHE
Life1 Normal: 6,000 / Eco: 12,000 hoursProjection Lens: Type: No optical zoom / Focus (Manual)
F-Number: 1.44
Focal Length: 16.4mm
Zoom Ratio: 1.0 – 1.35 (Digital Zoom)
Throw Ratio: 1.19 – 1.61

Connectivity:


USB Interface: USB Type A: 1 (for Wireless LAN, Firmware Update, Copy OSD Settings)
USB Type B: 1 (For Firmware Update and Copy OSD Settings)Network: Wired LAN: N/A
Wireless: OptionalAnalog Input: D-Sub 15pin: N/A
Composite: N/AAudio Input: N/AAudio Output: N/AVideo Input: HDMI: 1

Screen Size (Projected Distance):


Screen Size (Projected Distance): 34” to 391” [0.89 to 10.40m] (Zoom: Wide)
26” to 290” [0.91 to 10.41m] (Zoom: Tele)
Standard size: 60” screen 1.58m

Geometric Correction:


Vertical/Horizontal Keystone: Vertical: ± 30 degrees
Horizontal: ± 30 degreesAuto Keystone: N/AQuick Corner: Yes

Image Enhancement:


Scene Adaptive Gamma: YesAspect Mode: Yes

Start-Up Period:


Start-Up Period: About 6 seconds / Warm-up period: 30 seconds

Operating Temperature:


Operating Temperature: 5 - 40 °C <41 - 104 °F> (0m / 0ft - 2,286m / 7,500ft)
5 - 35 °C <41 - 95 °F> (over 2,286m / 7,500ft)
[20%-80% Humidity, No Condensation]

Operating Altitude:


Operating Altitude: 0 m to 3,048 m <0 ft to 10,000 ft>

Power:


Power Consumption: Lamp On (Normal / Eco): 270W / 214W
Standby (Network On / Off): N/A / 0.5WPower Supply Voltage: 100 - 240 V AC ±10%, 50/60 Hz

Internal Speaker(s):


Sound Output: 5W Monaural

Weight:


Weight: Approx. 2.4 Kg

Direct Power On/Off:


Direct Power On/Off: Yes

Dimension Excluding Feet:


Dimension Excluding Feet (D x W x H): 211 x 295 x 82 mm

Wireless Specifications (Smart Media Player Function):


Wireless LAN Generation : Wi-Fi 5Frequency Used: IEEE 802.11a (5GHz)*3,
IEEE 802.11b (2.4GHz)*3,
IEEE 802.11g (2.4GHz)*3,
IEEE 802.11n (2.4GHz and 5GHz)*3,
IEEE 802.11ac (5GHz)*3,Supported Codec: WPA2/WPA3-PSK (AES)

Colour Mode:


Colour Mode: Dynamic, Vivid, Cinema, Presentation, Blackboard, sRGB

Brightness:


White Light Output (Normal/Eco): 3,000 lm / 2,000 lmColour Light Output: 3,000 lmLight Output (Center): Yes [High, Low (Eco)]

Wireless Specifications (Optional Wireless LAN):


Supported Speed for Each Mode *: IEEE 802.11b (2.4GHz): 11 Mbps*3, IEEE 802.11g (2.4GHz): 54 Mbps*3, IEEE 802.11n (2.4GHz)*3: 72.2 Mbps*3, IEEE 802.11a (5GHz*3: 54 Mbps*3, IEEE 802.11n (5GHz)*3: 150 Mbps*3Supported Mode: Infrastructure, Access PointSupported Security Type: Infrastructure: Open, WPA2/WPA3-PSK
Access Point: WPA2-PSK (AES)

Cool Down Period:


Cool Down Period: Instant Off

Fan Noise:


Fan Noise (Normal / Eco): 38dB / 29dB

Specifications Projector:


Size - projected distance: 100” diagonal (wide: 9.3’ – tele: 19.8’) Contrast Ratio: Absolute Black (Full White 1500 lm / Full Black 0 lm) Projection Method: Front / rear / ceiling mount Projection System: 3LCD Reflective, 3-chip technology Poly-silicon TFT active matrix Pixel Number: 2,073,600 dots (1920 × 1080) × 3Color Brightness - Color Light Output: 1500 lumens *1Projected Output: HD, 2D, 3D, 1080pWhite Brightness - White Light Output: 1500 lumens *1Aspect Ratio: Native 16:9 widescreen (4:3 resize), compatible with 4:3 and 2.35:1 video formats with Normal, Full or Zoom Modes Driving Method: Epson Poly-silicon TFT active matrix, 0.74-inch wide panel Reflective HTPS Native Resolution: Native 1080p (1920 × 1080) Laser Type: Laser Diode 41.9 mW (Output) Light Source Life: Up to 20,000 hours (ECO Mode)*2

Colour Mode:


Colour Mode: Dynamic, Bright Cinema, Natural, Cinema, Adobe RGB, Digital Cinema, 3D Dynamic, 3D Cinema

Notes:

1 Color brightness (color light output) and white brightness (white light output) will vary depending on usage conditions. Color light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118.
